Getting Building Plans Approved

January 4, 2018



To the uninitiated Council submission can be a minefield! fraught with pitfall and potential delays that can cost you during the construction phase. It is vitally important that you do your homework before drawing up plans.  This will save a lot of time and expense later on.



1) Get initial documentation



You will have to obtain previous plans from the Council and a copy of your SG (Surveyor General) diagram and Zoning Certificate.  The SG diagram clearly shows your properties boundaries/area and neighboring stands.   The Zoning Certificate will tell you what the zone use of your property is - agricultural, business, commercial, residential 1, 2 or 3 and Special Use.  Residential 2 or 3 usually indicates your property is in a cluster / townhouse development.

The Building Lines are invisible lines on your property demarking the point up to which you can build - garden / boundary walls are not included.  Typically building lines are 5m at the front, 2m at the sides and 3m at the back.  However Building Lines vary from street to street and it's best not to make assumptions.

Building Lines can be relaxed - you will need your neighbours consent and the Municipal Town Planning Department approval.  As Town Planning Departments are notoriously understaffed it is best to use the services of a town planner or architect with contacts.

Coverage is the Building footprint on the stand - in other words what percentage of the stand is covered by a roof?  Paving, Driveways, swimming pools and boundary/garden walls do not count towards coverage in SA.  Coverage is typically 50% for a single or double storey dwelling / building and 40% for a three storey building.

F.A.R - Floor Area Ratio is the percentage living space allowable on the stand - so bedrooms, lounges, kitchens, servant's quarters etc. will count, but garages, covered patios, lapas, sheds, swimming pools and store-rooms etc. do not.  F.A.Rs vary between 0.3 - 1.2.  A low F.A.R - 0.6 for example - will effectively ensure that the first floor is smaller than the ground floor in a double storey building.

You will also need to obtain a copy of the title deeds if you don't already have a copy.  This is not only to confirm that you are the owner of the property; but also because title deeds usually have restrictive clauses within them.  This could affect the outcome of your building plan application.  Typically title deeds indicate that there is a 2m servitude on two boundaries other than a street boundary or pan-handle.  Further restrictions such as prohibiting metal roofs or wooden buildings are also common.  Title Deeds can be obtained from your transferring Attorney, the bank (if your property is mortgaged) or the Deeds Office.

Restrictive Clauses within a Title Deed can be removed - this involves an application through the Town Planning Department.  Consent can also be granted for extra coverage / F.A.R.  However this is a lengthy process and I strongly recommend that you use a Town Planner.

If your property is within an estate or town house / cluster complex you will also need to get a copy of the Estate Guidelines from the Aesthetics Committee  / Body Corporate / Residents Association etc.  You will find a list of requirements that ensure Aesthetic harmony and good building practice within the estate / complex.  In addition you will need your plans stamped and a letter from the Body Corporate for Council indicating that they are happy with your planned building.



2) Appoint Architect or Designer



Appoint a SACAP (South African Council for the Architectural Profession) registered Architect/Designer.  A list of registered professionals can be found at www.sacapsa.com. In order to practice as an Architect or Designer it is compulsory to register with SACAP.


3) Appoint Registered Engineer



You will be required to appoint an Engineer to complete the Structural/Civil design if -

  • You are planing structural alteration to current buildings

  • You are constructing a new house / building.

  • Your Plans indicate - concrete floor / roof slabs, wooden floors, Juliet Balconies, steel construction, timber frame construction and cellars.

  • Your stand has poor soil quality or is on a slope.



4) Get Required approvals



Prior to plan submission you will need approval and stamps from the following -

  • Fire Department - if your property is zoned business, commercial, special use or if you are building with thatch or timber frame construction.

  • Water / Sewerage department - if you are applying for Building Line Relaxation, proposing a new house / building or doing major renovations.

  • Roads / Transportation Department - if you are applying for Building Line Relaxation.

  • Environmental Health - if your property is zoned agricultural, business, commercial or special use.



5) Compile submission pack



So for Plan Submission you will need -

  • 3 Copies of the building plans - 2 colour.

  • Application Form

  • SACAP Registration form

  • Title Deed

  • Fire Department/ Environmental Health / Roads / Water stamps etc. if applicable.

  • Engineer Certificate of Appointment / Completion - if applicable.

  • Permission letter and stamp from Body Corporate / Aesthetics Committee etc. if applicable.

  • Letter from Town Planning for Building Line Relaxation, Consent, Rezoning etc. if applicable.

  • Approved updated SDP (Site Development Plan) if applicable.

  • Plan Submission / Courier Fees.

  • Patience Lots of Patience



Make it Simple

 Or let us manage this on you behalf. We provide support and guidance throughout the whole process from Initiation, Design & Submission to Construction & Completion. We allow you to focus on your dream home without having to become distracted with the complications.



Contact us today for a free quote or help understanding the process
